Leviton IPS02 Manual⁚ A Comprehensive Guide
This comprehensive guide delves into the Leviton IPS02 Decora Motion Sensor, an energy-saving device designed for automatic light control․ It explores the sensor’s features, from its manual-on capability to its compatibility with various load types including LED, CFL, and incandescent bulbs, giving a full overview․
Overview of the Leviton IPS02 Motion Sensor
The Leviton IPS02 is a Decora-style motion sensor designed to automatically control lighting based on occupancy․ Functioning as a 180-degree PIR (Passive Infrared) manual-on wall box sensor, it offers both convenience and energy savings․ This sensor replaces a standard single-pole switch and is compatible with various load types, including LED, CFL, incandescent, and halogen lights, as well as fluorescent ballasts․ It helps prevent lights from being left on in vacant rooms and can be manually switched off at any time using the convenient push button․
The IPS02 can be configured to operate as either an occupancy sensor (automatic ON/Auto OFF) or a vacancy sensor (Manual ON/Auto OFF) offering flexibility for different applications․ Installation is simplified with side wire terminal screws, ensuring a secure and reliable connection․ Its segmented Fresnel lens design optimizes sensitivity and performance, providing reliable motion detection․ Faceplates are sold separately, with compatibility for Decora-style faceplates allowing for easy integration with existing decor․ The IPS02 is engineered to meet modern energy-saving needs in residential and commercial settings․
Installation Instructions for IPS02
Installing the Leviton IPS02 motion sensor involves several key steps to ensure proper functionality and safety․ First, turn off the power at the circuit breaker to prevent electrical shock․ Remove the existing switch from the wall box, carefully noting the wire connections․ Identify the load wire, neutral wire, and line wire․ Connect the corresponding wires to the IPS02 using the side wire terminal screws, ensuring a secure connection․
The IPS02 is designed for single-pole wiring configurations․ After wiring, gently fold the wires into the wall box and secure the IPS02 using the provided screws․ Attach a Decora-style faceplate (sold separately) to the sensor․ Restore power at the circuit breaker and test the sensor’s operation; The IPS02 can be configured as either an occupancy or vacancy sensor, with adjustments made according to the specific application․ Ensure the sensor is properly mounted and all connections are tight before completing the installation․ Always consult the full manual for detailed instructions and safety guidelines․
Wiring Options and Specifications
The Leviton IPS02 Decora Motion Sensor is designed primarily for single-pole wiring configurations․ This means it replaces a standard single-pole switch, controlling a light or other load from one location․ The IPS02 features clearly labeled terminals for line (hot), load, and neutral wires․ It does not require a ground wire in most installations, but local codes should always be consulted to ensure compliance․
The sensor supports various load types, including LED, CFL, incandescent, and halogen, with specific wattage ratings․ For LED and CFL loads, the maximum is typically 150W, while incandescent and halogen loads can go up to 300W․ It’s important to adhere to these specifications to prevent damage to the sensor or the connected load․ The IPS02 can also handle 200VA fluorescent ballast loads․ The wiring should be done carefully, ensuring that all connections are secure using the side wire terminal screws․ Incorrect wiring can lead to malfunction or pose a safety hazard, so consulting the detailed manual is crucial․
Operating Modes⁚ Vacancy vs․ Occupancy Sensor (Manual ON/Auto OFF)
The Leviton IPS02 offers two distinct operating modes to cater to different user preferences and energy-saving needs⁚ vacancy and occupancy sensing․ In occupancy mode (Auto ON/Auto OFF), the sensor automatically turns the lights on when it detects motion in the room and turns them off after a set period of inactivity․ This mode is ideal for areas where lights are frequently needed, such as hallways or closets․
Conversely, in vacancy mode (Manual ON/Auto OFF), the lights must be manually turned on using the push button on the sensor․ However, the sensor still automatically turns the lights off after a period of inactivity․ This mode is beneficial for maximizing energy savings in areas where users might forget to turn off the lights, such as offices or restrooms․ The IPS02 allows users to switch between these modes based on their specific requirements, providing flexibility and control over their lighting system․ To operate the IPS02 as a vacancy sensor, adjust the ambient light control settings․
Adjusting Settings⁚ Ambient Light Control
The Leviton IPS02 motion sensor features an adjustable ambient light control setting, allowing users to fine-tune the sensor’s sensitivity to ambient light levels․ This setting determines the threshold at which the sensor will activate the lights in occupancy mode (Auto ON)․ By adjusting this setting, users can prevent the lights from turning on during the day when there is sufficient natural light, further enhancing energy savings․
To adjust the ambient light control, locate the corresponding dial or switch on the sensor․ Rotating the dial towards the “+” symbol increases the sensitivity, meaning the sensor will activate the lights even in brighter conditions․ Conversely, rotating the dial towards the “-” symbol decreases the sensitivity, preventing the lights from turning on unless the room is relatively dark․ This feature allows for customized control, ensuring that the lights only activate when needed, based on the specific lighting conditions of the environment․ When the dial is turned all the way to the “-” symbol, the IPS02 functions as a vacancy sensor, requiring manual activation․
Troubleshooting Common Issues
Encountering issues with your Leviton IPS02 motion sensor? Here’s a guide to troubleshooting common problems․ If the sensor fails to detect motion, first ensure that the sensitivity settings are appropriately adjusted for the environment․ Obstructions blocking the sensor’s view can also hinder detection; clear any obstacles in the sensor’s range․
If the lights turn on and off erratically, check for sources of interference, such as HVAC vents or moving objects, that might trigger false detections․ Adjusting the sensor’s field of view or repositioning it can mitigate these issues․ Also, confirm that the wiring connections are secure and correct, as loose or incorrect wiring can lead to malfunctions․ If the lights do not turn on at all, verify that the power supply is active and that the sensor is receiving power․ If the problem persists, consult the Leviton IPS02 manual for advanced troubleshooting steps or contact Leviton customer support for assistance․ Always prioritize safety when working with electrical components․
Compatible Loads⁚ LED, CFL, Incandescent
The Leviton IPS02 motion sensor offers versatile compatibility with a range of lighting loads, making it suitable for diverse applications․ It is engineered to control LED, CFL, and incandescent lighting effectively․ When using LED or CFL bulbs, it’s essential to consider the wattage limitations specified in the IPS02 manual to avoid overloading the sensor․ For incandescent lighting, the IPS02 typically supports higher wattage loads, but adhering to the recommended limits is crucial to ensure optimal performance and prevent damage․
The IPS02 is also designed to handle electronic and magnetic low voltage loads․ Always consult the product specifications to verify compatibility and wattage ratings before connecting any lighting fixture․ Proper load matching guarantees efficient operation and extends the lifespan of both the sensor and the connected lights․ Selecting compatible loads ensures the Leviton IPS02 functions reliably and provides energy-saving benefits․
Decora Compatibility⁚ Faceplate Options
The Leviton IPS02 motion sensor is designed with Decora compatibility in mind, allowing for seamless integration into existing Decora-style switch plates․ This compatibility provides homeowners and installers with a wide range of aesthetic options to match their interior decor․ Faceplates are sold separately, offering the flexibility to choose colors and finishes that complement the surrounding environment․
Decora faceplates are available in various colors, including white, ivory, and light almond, ensuring a cohesive look throughout the home․ The Decora design provides a clean, modern appearance, enhancing the overall aesthetic appeal of the installation․ When selecting a faceplate, ensure it is specifically designed for Decora devices to guarantee a proper fit and secure attachment․ The modular design simplifies the installation process, allowing for quick and easy customization․
Where to Find the Leviton IPS02 Manual and Support
Finding the Leviton IPS02 manual and accessing support resources is straightforward․ The manual is typically available for download on the Leviton website, often in PDF format․ You can find it by searching for the IPS02 model number on the Leviton support page․ This manual provides detailed installation instructions, wiring diagrams, and troubleshooting tips․
In addition to the manual, Leviton offers various support channels․ Their website includes a comprehensive FAQ section addressing common questions about the IPS02․ For more specific inquiries, you can contact Leviton’s customer support team via phone or email․ They can provide expert assistance with installation, configuration, and troubleshooting․
Online forums and communities dedicated to home automation and electrical projects can also be valuable resources․ These platforms allow users to share their experiences with the IPS02 and offer peer-to-peer support․ Checking video platforms may offer useful tutorials too․
